Email Header Analyzer

Message headers record every server a message passed through and what each receiver thought of it. Paste them here to turn the wall of text into a readable path — parsed in your browser. Only the sending IP address and the domains are sent to our server, for live SPF, DKIM key and DMARC lookups; the headers themselves are not uploaded.

Getting the headers

Gmail: open the message » three-dot menu » Show original. Outlook desktop: File » Properties » Internet headers. Outlook on the web: three-dot menu » View » View message source. Apple Mail: View » Message » All Headers. Copy everything above the message body.

The first hop is the sender’s own mail server or client; a long delay on a middle hop means that server queued the message, often because of greylisting, rate limits or a busy spam filter.

Email header analyzer at a glance

How to use this tool

1. Open the original message (not a forwarded copy) and copy the full headers using the steps above. Pasting the whole message source also works: the analyzer stops at the first blank line, where the body starts.
2. Paste the text into the box and press Analyze headers. Anything shorter than a few lines is rejected, because a single header is not enough to trace a message.
3. Read the summary first: who sent it, which server handed it over, and the SPF, DKIM and DMARC verdicts.
4. Then read the two tables: the authentication results each receiving server wrote down, and the delivery path from the oldest hop to the newest.
5. If DKIM is the open question, send a fresh copy of the same kind of message to the email deliverability test. Headers alone cannot prove a DKIM signature, because the signature also covers the body.

Parsing happens in your browser. After parsing, the page sends only the sending IP, the Return-Path and From domains and up to four DKIM domain and selector pairs to our server, which looks up SPF, DMARC and the DKIM keys in DNS as they are now.

How to read the results

The summary only shows rows the headers actually contain. Each verdict is coloured: green for pass, red for fail, softfail and permerror, amber for anything in between such as neutral, none, temperror or a DMARC pass under p=none.

Row	What it means
From, To, Subject, Date, Message-ID	Copied exactly as written by the sender. The From address is the one people see, and it is the domain DMARC protects.
Return-Path	The envelope sender (MAIL FROM) recorded by the last server. SPF is checked against this domain, not against From.
Sending server	The public IP that handed the message to the receiving system, with the HELO name it used. The analyzer reads the newest Received header that names an IP in square brackets, skipping LMTP and local delivery hops and private addresses. If this row is missing, the live SPF check is skipped.
SPF	The verdict the receiver recorded, then live check now: our own SPF evaluation of the same IP and Return-Path domain against the record published today, with the mechanism that matched.
DKIM	The recorded verdict, then every signature found (up to four) with its domain (d=), selector (s=), algorithm, whether the public key exists in DNS now and its size, and aligned with From when the signing domain matches the From domain.
DMARC	The recorded verdict. If the receiver did not record one, the analyzer works it out from the SPF and DKIM alignment and the policy published now. The policy (p=, and pct= below 100) is shown; a subdomain uses the parent’s sp= value when it has no record of its own.
Hops	How many Received headers the message collected. Large providers add several internal hops of their own, so a high count is not a problem by itself.
Total delay	The sum of the gaps between hop timestamps. It turns amber above 300 seconds.
Spam filter	The raw value of X-Spam-Status, X-Spam-Score, X-Microsoft-Antispam or X-Forefront-Antispam-Report, whichever comes first.
Alignment note	Shown when the From and Return-Path domains differ. SPF can then never align, so DMARC depends on a DKIM signature from the From domain.

In the delivery path table the Protocol column shows how each hop was received. ESMTPS means TLS was used, ESMTPA means the client logged in, and ESMTPSA means both (RFC 3848). Plain SMTP or ESMTP between two servers means the hop was not encrypted. A negative delay means one server’s clock is wrong; it is shown but not added to the total.

Microsoft 365 and Outlook.com headers

Microsoft writes its verdict into X-Forefront-Antispam-Report and adds a compauth (composite authentication) result to Authentication-Results. The fields worth reading:

Field	Meaning
CIP	The connecting IP address.
SFV	Spam filter verdict: NSPM not spam, SPM spam, SKA/SKI/SKN filtering skipped because of an allow list, IP allow list or mail flow rule.
CAT	The category that decided the outcome, for example SPM, HSPM, BULK, PHSH or SPOOF.
SCL	Spam confidence level from -1 to 9. Microsoft notes that in the cloud it no longer decides the verdict, so read SFV and CAT instead.
compauth=fail reason=000	DMARC failed and the domain’s policy is quarantine or reject.
compauth=fail reason=001	Implicit failure: the domain has no authentication records, or only weak ones such as ~all or p=none.
compauth=pass reason=1xx	Authentication passed and aligned with the From domain.

Common problems and how to fix them

“dkim=neutral (body hash did not verify)”

The signature header is intact but the body changed after signing. Typical causes are a mailing list or gateway that adds a footer or disclaimer, an antivirus scanner that rewrites links, or a relay that re-encodes the message. Sign on the last server that touches the message, or add footers before the DKIM signing step. Mail through mailing lists usually survives DMARC only when the list adds ARC headers or rewrites the From address.

“spf=softfail … does not designate 203.0.113.10 as permitted sender”

The IP that delivered the message is not in the SPF record of the Return-Path domain. Find out what sent it (the Sending server row), then add the provider’s include: or the server’s ip4: to the record. Check what is published now:

dig +short TXT example.com | grep spf1

“spf=permerror”

The receiver could not evaluate the record at all: the domain publishes two v=spf1 records, the syntax is broken, or evaluation needs more than 10 DNS lookups. Merge everything into one record and flatten includes you no longer use. See SPF too many DNS lookups.

DKIM key shows “NO key in DNS”

The selector named in s= has no public key published, so every receiver will fail the signature. Publish the key your mail server or provider shows, or switch signing to a selector that exists. On an old message this can also mean the key was rotated since; that is expected and harmless. To find which selector a sender uses, read find a DKIM selector.

dig +short TXT default._domainkey.example.com

One hop with a long delay

The server named in the By column of the slow hop held the message. Greylisting adds a few minutes on first contact; longer gaps point at a queue backlog, a rate limit at the next provider, or a server that could not reach the next hop and retried. On a cPanel or DirectAdmin server running Exim, search the log for the message:

exigrep 'example.com' /var/log/exim_mainlog

On Postfix servers the same lines are in /var/log/maillog (RHEL family) or /var/log/mail.log (Debian and Ubuntu).

No sending server is shown

Either the headers were cut off before the first external hop, or the message was submitted from a mail client on a private network and the provider did not record a public IP. Copy the headers again from the original message. A message you forwarded to yourself only shows the forwarding path, not the original sender.

BLOCKED rules in X-Spam-Status

Rules such as URIBL_BLOCKED mean the receiving SpamAssassin could not query a blacklist because it uses a public DNS resolver that the list refuses. The fix belongs on the receiving server (use a local caching resolver), not in your message.

Official documentation: DirectAdmin documentation, cPanel & WHM documentation, RFC 5321 (SMTP).

Related guides: Warm up a new mail server IP or sending domain without landing in spam · Configuring DirectAdmin’s Exim to relay through MailBaby · Choosing a VPS for a cPanel or DirectAdmin server in 2026.
