Cloudflare Error 521, 522 and 525 on cPanel: Fixes

Diagnose and resolve Cloudflare 521 (origin refused), 522 (connection timed out) and 525 (SSL handshake failed) on cPanel servers by checking CSF blocks, Apache status, origin certificates and the SSL mode, with commands to verify each fix.

Published Updated 7 min read

Update, 9 October 2026: the origin test now keeps the handshake check (curl -Ik) separate from the certificate check (without -k), because -k skips certificate verification and certificate failures in Full (strict) mode are 526. Found in an independent review.

Applies to cPanel & WHM servers running Apache (EasyApache 4) behind Cloudflare-proxied DNS records, with Cloudflare SSL/TLS encryption mode Flexible, Full or Full (strict), as described in the current Cloudflare and cPanel documentation.

Short answer: All three errors come from the origin, not from Cloudflare. Cloudflare error 521 means the cPanel server refused the connection: Apache is stopped or a firewall such as CSF is rejecting Cloudflare’s IP ranges. 522 means the connection timed out: packets are dropped, the server is overloaded or the DNS record points to the wrong IP. 525 means the TLS handshake failed in Full or Full (strict) mode: no valid certificate on port 443, no SNI support or no shared cipher. Test the origin directly with curl -Ik --resolve example.com:443:ORIGIN_IP https://example.com/, which shows whether the TLS handshake completes. Repeat it without -k to check the certificate as well; a certificate that fails that check gives 526 in Full (strict) mode, not 525. (Reviewed October 2026.)

When a site behind Cloudflare shows a 5xx page with the Cloudflare branding, the edge could not complete a request to your cPanel server. The three codes in the title map to three distinct failure points, and knowing which one you have cuts the diagnosis time in half. Error 521 means the origin actively refused the TCP connection. Error 522 means the connection attempt timed out with no reply. Error 525 means TCP connected but the TLS handshake with the origin failed. All three are origin-side problems, not Cloudflare outages, although a Cloudflare status incident is worth ruling out first.

Confirm which side is failing

Test the origin without Cloudflare in the path from a machine outside the server’s own network:

curl -Ik --resolve example.com:443:203.0.113.10 https://example.com/
curl -I --resolve example.com:80:203.0.113.10 http://example.com/

A refused connection points to 521, a hang to 522, and a handshake error such as alert handshake failure to 525. -k tells curl to skip certificate checks, so this test cannot show an expired, self-signed or wrong-name certificate. Run it once more without -k (curl -I --resolve example.com:443:203.0.113.10 https://example.com/). If only that run fails with a certificate error, the handshake works and the certificate is the problem, which Full (strict) mode reports as 526. For a Cloudflare Origin CA certificate, add --cacert with Cloudflare’s origin CA root, because public trust stores do not include it. Then check whether the problem is global or limited to Cloudflare’s addresses by running the same test from the server’s own shell against its own public address with curl -Ik --resolve example.com:443:203.0.113.10 https://example.com/. A request to 127.0.0.1 with only a Host header is not a reliable test, because Apache selects the virtual host by the connection’s IP and port first and no SNI name for the domain is sent. If local works and remote fails, the network or firewall is involved.

Error 521: origin refused

On the cPanel server confirm Apache is running and listening:

systemctl status httpd
ss -ltnp | grep -E ':(80|443) '
/scripts/restartsrv_httpd

Common causes are Apache having crashed after a configuration change, a stale httpd.conf rebuild, or a site whose IP was changed in WHM » Change a Site’s IP Address without the DNS record in Cloudflare being updated. Compare the A record in the Cloudflare dashboard with the address in /etc/userdatadomains for the account. If Apache is fine and the port is open, check that CSF is not returning a TCP reset for Cloudflare: csf -g 173.245.48.1 shows whether an address is in the deny list or the temporary block list.

Error 522: connection timed out

Timeouts are nearly always a firewall dropping packets or a server too busy to answer. Start with CSF and LFD, because Cloudflare’s shared addresses trip login-failure and port-scan triggers easily when many sites share them. Add the current Cloudflare IPv4 and IPv6 ranges to /etc/csf/csf.allow and /etc/csf/csf.ignore, then restart:

csf -a 173.245.48.0/20 Cloudflare
csf -ra
grep -c "Cloudflare" /etc/csf/csf.allow

Repeat for each published range, and keep the list refreshed because ranges change occasionally. If you use Imunify360 instead of or alongside CSF, whitelist the ranges there as described in Whitelist IPs and countries in Imunify360 from the CLI. Next check load: uptime and top on a server that is swapping will show the reason at once, and Apache’s MaxRequestWorkers being exhausted produces intermittent 522s under traffic. Finally confirm the origin’s own upstream is not the problem: an ISP null route after a DDoS makes every Cloudflare request time out while local tests succeed.

Error 525: SSL handshake failed

A 525 means Cloudflare connected but could not agree on TLS. Cloudflare lists the causes as no valid certificate installed on the origin, port 443 not open, no SNI support, or no cipher suite in common, and the error only appears when the SSL mode is Full or Full (strict). If the handshake completes but the certificate is self-signed, expired or issued for a different name, Full (strict) returns error 526 instead of 525; the same check below shows both cases. Check what the origin presents:

openssl s_client -connect 203.0.113.10:443 -servername example.com </dev/null 2>/dev/null | openssl x509 -noout -subject -issuer -dates

If no certificate is returned, or the subject is the server hostname or the dates are expired, run AutoSSL for the account with /usr/local/cpanel/bin/autossl_check --user=account or install a Cloudflare Origin CA certificate through WHM » Install an SSL Certificate on a Domain. Alternatively drop the Cloudflare mode to Full while the origin certificate is sorted out; do not use Flexible, which sends plain HTTP to the origin and breaks anything that redirects to HTTPS. Note that AutoSSL’s HTTP validation can itself fail behind the proxy; the DNS proxy and real IP guide covers the DCV exceptions.

Verify and prevent recurrence

After the fix, load the site through Cloudflare with curl -I https://example.com/ and look for the cf-ray header, which proves the request went through Cloudflare; a cf-cache-status of DYNAMIC or MISS confirms the origin answered, whereas HIT was served from Cloudflare’s cache without reaching the origin. Then add the Cloudflare ranges to the firewall’s allow lists permanently and install a real-IP module so the logs show visitor addresses rather than Cloudflare’s, otherwise the next LFD block will be a repeat. The common pitfall is whitelisting only IPv4 while the zone is also served over IPv6, so Cloudflare’s IPv6 connectors still get blocked and the error returns intermittently.

Cloudflare 521, 522 and 525 errors comparedError 521 means the origin refused the connection, 522 that it did not answer in time, and 525 that the SSL handshake with the origin failed.Which part of the path failed521Web server downOrigin refused the TCPconnection.Check: web service running,firewall allows CF IPs.522Timed outOrigin did not answerin time.Check: DNS points to theright IP, server load,dropped packets.525TLS failedTCP worked but TLS didnot.Check: valid cert on 443,SNI / vhost for the name,SSL mode Full (strict).
Diagram: 521 = origin refused, 522 = origin timed out, 525 = TLS handshake with the origin failed.

Official documentation (checked 9 October 2026): Error 521 · Cloudflare Support docs · Error 522 · Cloudflare Support docs · Error 525 · Cloudflare Support docs · Error 526 · Cloudflare Support docs · Flexible – SSL/TLS encryption modes · Cloudflare SSL/TLS docs · IP Ranges · Cloudflare · Cloudflare HTTP headers · Cloudflare Fundamentals docs · Cloudflare cache responses · Cloudflare Cache (CDN) docs · Restoring original visitor IPs · Cloudflare Support docs · The autossl_check Script · cPanel & WHM documentation · An In-Depth Discussion of Virtual Host Matching · Apache HTTP Server 2.4

Related guides: Cloudflare Tunnel (cloudflared): expose an internal service without opening ports · Cloudflare in front of cPanel: DNS, proxy mode and real visitor IPs done right · AutoSSL failed: fixing DCV errors, CAA records, CDN proxies and blocked /.well-known/.

Frequently asked questions

Does Cloudflare error 522 also appear when the cPanel server is under a DDoS attack?

Yes. If the origin’s network is saturated or the provider has null-routed the IP, Cloudflare’s connection attempts time out and every visitor sees a 522 even though the server itself is up.

How long does it take for a Cloudflare 525 fix to take effect?

Changing the SSL mode or installing a new origin certificate takes effect within a minute or two, since Cloudflare does not cache the TLS failure for long; retry after clearing the browser cache.

Can I undo whitelisting Cloudflare ranges in CSF?

Yes. Remove the lines from /etc/csf/csf.allow and /etc/csf/csf.ignore, then run csf -ra; however, without them a busy Cloudflare-fronted server will block the edge again sooner or later.
